wide-tempereature display panel

1.43 inch round AMOLED on-cell touch display shown in a wide temperature operation concept from -40°C to 85°C.

What is Wide Temperature Operation

For some products that need to be used in cold places, such as Russia, Canada, and Southern Europe, or for some military applications, the display panel must work well under - 40 degrees.

Wide temperature display panels are designed for devices that need stable performance in cold, hot, outdoor, vehicle, industrial, or rugged environments. Compared with standard indoor displays, they are better suited for products that may face cold starts, direct sunlight, enclosure heat, long operating hours, or changing working conditions.

Panox Display provides wide temperature options across OLED, AMOLED, Micro OLED, Memory LCD, TFT-LCD, flexible AMOLED, mobile display, and industrial LCD products. These displays can be used in AR/VR optics, wearables, handheld instruments, automotive systems, outdoor terminals, and industrial control devices.

Narrow Your Results:

Size(inch)
- 0.39~1.0
- 1.0~1.9
- 2.0~2.9
- 3.0~3.9
- 4.0~4.9
- 5.0~5.9
- 6.0~6.9
- 7.0~7.9
- 8.0~9.9
- 10~20
Interface
- I2C
- SPI
- Parallal
- MCU
- CPU
- RGB
- MIPI
- LVDS
- eDP
- HDMI
Display Color
- Monochrome
- Double Color
- Full Color
Orientation
- Landscape
- Portrait

Products Industrial LCD Mobile Display PMOLED AMOLED TFT-LCD Memory LCD Flexible Display Screen Raspberry Pi Display Micro OLED Display

Model

Size

Display Type

Resolution

Interface

Display Brand


2.6 inch OLED RGB MCU Interface For Handheld

Size	2.6
Display Type	AMOLED
Resolution	240(RGB)×320 , QVGA
Interface	SPI,RGB
Display Brand	Samsung

2.6

AMOLED

240(RGB)×320 , QVGA

SPI,RGB

Samsung

2.7 inch Full Color OLED Display 1ms Response Time MIPI DSI 2 Lanes

Size	2.69
Display Type	OLED , AM-OLED
Resolution	800x600
Interface	MIPI
Display Brand	BOE

2.69

OLED , AM-OLED

800x600

MIPI

BOE

2.7 inch PMOLED For Instrument

Size	2.7
Display Type	PMOLED
Resolution	128×64
Interface	I2C,SPI,Parallal
Display Brand	Ritdisplay

2.7

PMOLED

128×64

I2C,SPI,Parallal

Ritdisplay

2.8 inch OLED C0283QGLA For Handheld

Size	2.8
Display Type	AMOLED
Resolution	240(RGB)×320
Interface	SPI,Parallal,RGB
Display Brand	CMEL

2.8

AMOLED

240(RGB)×320

SPI,Parallal,RGB

CMEL

2.95 inch OLED For VR

Size	2.95
Display Type	AMOLED
Resolution	1080(RGB)×1200
Interface	MIPI
Display Brand	EDO

2.95

AMOLED

1080(RGB)×1200

MIPI

EDO

3.0 inch OLED For Handheld

Size	3.0
Display Type	AMOLED
Resolution	240(RGB)×400 [WQVGA]
Interface	MIPI
Display Brand	Samsung

3.0

AMOLED

240(RGB)×400 [WQVGA]

MIPI

Samsung

3.2 inch Memory LCD Colorful/Chromatic For Handheld

Size	3.2
Display Type	Memory LCD
Resolution	336×536
Interface	SPI
Display Brand	Sharp

3.2

Memory LCD

336×536

SPI

Sharp

3.26 inch OLED For Handheld

Size	3.26
Display Type	AMOLED
Resolution	854(RG/BG)×480 , FWVGA
Interface	SPI,RGB
Display Brand	Samsung

3.26

AMOLED

854(RG/BG)×480 , FWVGA

SPI,RGB

Samsung

3.47 inch OLED For Handheld

Size	3.47
Display Type	AMOLED
Resolution	360x640
Interface	MIPI
Display Brand	Samsung

3.47

AMOLED

360x640

MIPI

Samsung

3.5 inch OLED 90 Hz For VR

Size	3.5
Display Type	AMOLED
Resolution	1440(RG/BG)×1600
Interface	MIPI
Display Brand	Samsung

3.5

AMOLED

1440(RG/BG)×1600

MIPI

Samsung

3.81 inch OLED 90Hz For VR

Size	3.81
Display Type	AMOLED
Resolution	1080(RGB)×1200
Interface	MIPI
Display Brand	AUO

3.81

AMOLED

1080(RGB)×1200

MIPI

AUO

3.92 inch AMOLED PCAP 1080 X 1240 Mipi

Size	3.92
Display Type	AMOLED
Resolution	1080 x 1240
Interface	MIPI,eDP
Display Brand	GVO (Visionox）

3.92

AMOLED

1080 x 1240

MIPI,eDP

GVO (Visionox）

What Makes a Display Suitable for Wide Temperature Operation?
First, most LCDs have a residual shadow in low temperatures, thermotropic liquid crystals are liquid crystal phases that occur as a result of temperature changes. At low temperatures, it is crystalline, and at high temperatures, it becomes liquid, where the melting point (TM) and the clear point (TC) are indicated. Single molecules of liquid crystal have their own melting point and clearing point and exist as liquid crystals at intermediate temperatures. At present, the liquid crystal materials used for display are basically thermotropic liquid crystals. In the thermotropic liquid crystal, the liquid crystal is divided into three types according to the molecular arrangement structure: SMECTIC, NEMATIC, and CHOLESTERIC. Low temperature will cause the liquid crystal to become solid, and the response speed is reduced, resulting in residual shadow.

But OLED pixels are solid-state, so OLED can still work well under low temperatures such as - 40 degrees. BTW, some Memory LCD or Transflective LCD also can work well under -15 degrees.

A wide temperature display should remain usable when the surrounding environment becomes colder or hotter than normal room conditions. This includes stable image output, acceptable response speed, reliable interface communication, and consistent brightness or contrast.

For LCD products, low temperature may slow liquid crystal response and cause image delay or residual shadow. OLED and AMOLED displays are often suitable for compact low-temperature applications because their pixels are self-emissive. Memory LCD and transflective display options can also be useful for low-power outdoor devices.

Common Applications for Wide Temperature Displays

Wide temperature displays are commonly used in vehicle displays, industrial HMIs, handheld terminals, outdoor instruments, medical devices, smart watches, AR/VR viewers, electronic viewfinders, testing equipment, and public service machines.

Different applications need different display solutions. A vehicle console may require a high-brightness LCD with touch support, while an AR optical engine may need a compact Micro OLED. A wearable device may use a small AMOLED or flexible OLED, and a low-power outdoor meter may benefit from Memory LCD.

More About Wide Temperature Display Panels
What Is a Wide Temperature Display? A Practical Guide for Industrial LCD and OLED Selection
Why Is Wide Temperature Operation Important for OLED and LCD Display Products?
Wide Temperature Display Applications: Choosing the Right OLED and LCD Module for Real Product Environments

Customized Service

customized_display_service

It`s just a beginning to get display panels from us, then clients need to solve cover glass/touch panel, driving board, connectors on PCB.Fortunately Panox Display provide complete display solutions.

Connectors

Panox Display provides free connectors for clients who purchase more than five products from us. Our product range includes connectors from Molex, Kyocera, AXE, AXG, JAE, Hiros, and more.

Cover Glass/Touch Panels

Panox Display provides a customized cover glass/touch panel service. We supply cover glass from Gorilla, AGC, and Panda, which all have excellent optical performance. We also supply driver ICs from Goodix and Focaltech.

Controller/Driver Boards

If your applications are directly connected to a PC, a cellphone, or Raspberry Pi, and you have enough space to insert a board to input video, Panox Display can provide customized Controller/Driver boards with input connections for VGA, HDMI, DVI, DP, Type-C video input, MIPI, RGB, LVDS, and eDP.
The functions of our boards include, but are not limited to, adjustment of brightness, sound output, touch interface, extra data transmission, and gyroscope.
