Model: H163QLN01.1/H163QLN01.2

Panox Display`s 1.63 inch OLED  supports display 320(RGB)×320 with an aspect ratio of 1:1 (W: H), whose pixels are arranged in RGB Vertical Stripe, according to the calculation of Panox Display its pixel density is 277 PPI. As for mechanical detail, it features an active area of 29.28(W)×29.28(H) mm, outline size of 32.08(W)×36.48(H)×1.38(D) mm. This 1.63 inch OLED can provide 300 cd/m² display brightness 10000:1 transmissive contrast ratio, 80/80/80/80 (Min.)(CR≥1600) (L/R/U/D) viewing angle, best view direction on Symmetry, and response time of 1 (Max.)(Tr+Td) ms. Grayscale or the brightness of the sub-pixel is determined with an 8-bit grayscale signal for each dot, thus presenting a palette of 16.7M colors, also with the performance of color gamut 103% (NTSC). This product emits itself.


H163QLN01.0/H163QLN1.1 utilizes MIPI (1 data lane) as its signal inputting system, which is connected by 20 pins Connector with a power supply voltage of 1.8/3.0/4.6/3.4V (Typ.)(IOVDD/VDD/ELVDD/ELVSS).
This MIPI interface is easy to control by MCU such as SSD2828, STM469 or higher, AVR, ARDUINO, ARM, and Raspberry Pi

OLED display have advantages as follows,

Thin Like Paper: More than 50% thinner and lighter than LCD, creating an edgy form factor in style
Low  Power Consumption: Clock-mode standby can be up to 60 hours
True Color: High contrast ratio and wide color gamut offer sharp and vivid images, and consistent display from any angle.
Readable Under Sun
Wide View Angle
Wide Temperature Operation: Work well at low temperature -40℃
Pure Black Color

Panox Display provide SSD2828 FPGA Board to drive this 1.63 inch OLED

Customized CTP(capacity touch panel)  is available
